All stainless steel structure, acid and alkali resistant, with bottom vibration type, side vibration type, top vibration type three cleaning conditions. It includes the following aspects: removal of oil and rust from electrophoresis oxidation plant and mechanical parts; high-definition cleaning of precision parts; surface activation treatment of metal workpieces; cleaning of experimental utensils of medical devices; cleaning of metal filter screen, etc.
Ultrasonic vibration plate immersion ultrasonic vibration plate
Can be customized according to the requirements: ultrasonic vibration plate size, material, thickness, hose, hard tube, outlet direction, power size, outlet pipe length, number of transducers, input type or wall mounted type, etc.
Application scope of Top type Ultrasonic Immersion Transducer Box for cleaning
Cleaning electroplating parts before plating, watch and clock parts, hardware and machinery parts, polyester filter element, semiconductor silicon chip, tools, lenses, glasses frame, jewelry, glassware, special matching of ceramic ball mill, etc
Type |
Diamention(mm) |
Frequency (Khz) |
Power(W) |
Ultrasonic Transducer |
PU-UITP300W |
300*190*100 |
25,28,33,40,80,130 |
300 |
6 |
PU-UITP600W |
360*275*100 |
25,28,33,40,80,130 |
600 |
12 |
PU-UITP1000W |
450*350*100 |
25,28,33,40,80,130 |
1000 |
20 |
PU-UITP1200W |
470*380*100 |
25,28,33,40,80,130 |
1200 |
24 |
PU-UITP1500W |
520*450*100 |
25,28,33,40,80,130 |
1500 |
30 |
PU-UITP1800W |
560*450*100 |
25,28,33,40,80,130 |
1800 |
36 |
PU-UITP2000W |
650*450*100 |
25,28,33,40,80,130 |
2000 |
40 |
PU-UITP2400W |
740*520*100 |
25,28,33,40,80,130 |
2400 |
48 |
PU-UITP3000W |
820*540*100 |
25,28,33,40,80,130 |
3000 |
60 |
PU-UITP5000W |
1200*590*100 |
25,28,33,40,80,130 |
5000 |
100 |
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power) |


TAG ultrasonic: Ultrasonic Immersion Transducer Box 2400 Watts Custom Ultrasonic immersible box Sus304 Stainless Steel Immersible Ultrasonic Transducer
