ultrasonic high power pulse generator for cleaning

In order to improve the complex defects of adjusting machine steps, the Digital Ultrasonic Generator upgrades and updates the circuit, program and components. After more than one year of repeated testing and customer practice, it has launched a more stable, more complete function and simpler debugging model, which is also the best ultrasonic generator in domestic cleaning industry.

Power adjustable function, the ultrasonic generator adopts a safe voltage regulation mode to adjust the output power of the ultrasonic generator steplessly. The frequency modulation mode is changed to adjust the power. Customers can choose the adjustment mode according to their needs.

It has the function of frequency adjustment: one ultrasonic power supply can adjust the use of multiple frequency bands. However, the company's engineers declare that the chip program of each frequency band is different, the inductance coil ratio is different, and the transformer wire diameter is different. Therefore, it is necessary to debug and use under the guidance of the manufacturer. If the frequency is changed in a wide range, the machine will be damaged.

Type	Power（W）	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
PU-GT300	300W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
PU-GT600	600W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
PU-GT900	900W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
PU-GT1000	1000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
PU-GT1200	1200W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
PU-GT1500	1500W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
PU-GT1800	1800W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
PU-GT2000	2000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
PU-GT2400	2400W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
PU-GT3000	3000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	65-80khz
High Frequency	300W-1200W	120-135khz
