25khz/28khz ultrasonic dishwasher generator

25khz/28khz ultrasonic dishwasher generator

Price：¥

Service quality：25khz/28khz ultrasonic dishwasher generator

Inquiry Immediately
Ultrasonic dishwasher uses the principle of ultrasonic atomization ion cleaning: when the ultrasonic wave passes through the liquid medium, it will compress the vibration of the liquid medium at a very high frequency, making the liquid molecules produce positive and negative alternating shock waves. When the sound intensity reaches a certain value, tiny cavitation bubbles grow rapidly in the liquid and close strongly instantaneously, resulting in strong micro explosion and shock wave, which destroy the dirt on the surface of the cleaned object and fall off the cleaned surface. Although the role of each cavitation bubble is not big, but there are hundreds of millions of cavitation bubbles per second, it has a good cleaning effect.

Type

Power（W）

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10%  USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

PU-DG300

300W

20khz,25khz,28khz
Frequency is adjustable

3-6

300x360x150

PU-DG600

600W

20khz,25khz,28khz
Frequency is adjustable

6-12

300x360x150

PU-DG900

900W

20khz,25khz,28khz
Frequency is adjustable

9-18

300x360x150

PU-DG1000

1000W

20khz,25khz,28khz
Frequency is adjustable

10-20

300x360x150

PU-GT1200

1200W

20khz,25khz,28khz
Frequency is adjustable

12-24

300x360x150

PU-DG1500

1500W

20khz,25khz,28khz
Frequency is adjustable

15-30

300x360x150

PU-DG1800

1800W

20khz,25khz,28khz
Frequency is adjustable

18-36

300x360x150

PU-DG2000

2000W

20khz,25khz,28khz
Frequency is adjustable

20-40

300x360x150

PU-DG2400

2400W

20khz,25khz,28khz
Frequency is adjustable

24-48

300x360x150

PU-DG3000

3000W

20khz,25khz,28khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

65-80khz

High Frequency

300W-1200W

120-135khz
